Cutler-Hammer Series FAZ-C4/1-NA-SP
EATON FAZ-C4/1-NA-SP Current Limiting Supplementary Protector, 277/480 V AC, 4 A, 10 to 14 kA Interrupt, 1 Poles, Thermal Magnetic Trip
Cutler-Hammer Series FAZ-C4/1-NA-SP
EATON FAZ-C4/1-NA-SP Current Limiting Supplementary Protector, 277/480 V AC, 4 A, 10 to 14 kA Interrupt, 1 Poles, Thermal Magnetic TripIn Stock: 5more info
|
BrandCutler-Hammer Series
MFG #FAZ-C4/1-NA-SP
Werner Part #3976749
In Stock: 5more info
|
BrandCutler-Hammer Series
MFG #FAZ-C4/1-NA-SP
Werner Part #3976749
Product Description
EATON Supplementary Protector, Current Limiting, Series: FAZ, 277/480 V AC, 4 A, 50/60 Hz Frequency, 10 to 14 kA Interrupt, Thermal Magnetic Trip, 1 Pole, Lever/Toggle Actuator, Standard Terminal Connection, 18 to 6 AWG Wire, IP20 Enclosure, DIN Rail Mounting, -40 to 75 deg C, 0.7 in L x 2.97 in W x 4.13 in H Dimensions, Nylon
Attributes
Documents
Applications
Warranty
Features
Attributes
Actuator TypeToggle Lever
Connection TypeStandard Terminal
Country of OriginES
Dimensions0.7 in L x 2.97 in W x 4.13 in H
Enclosure TypeIP20
Frequency Rating50/60 Hz
Interrupt Rating10 to 14 kA
ManufacturerEaton
MaterialNylon
Number of Poles1
SeriesFAZ
Size of Wire18 to 6 AWG
Temperature Rating-40 to 75 deg C
Trip TypeThermal Magnetic
TypeCurrent Limiting
Type / StyleType FAZ-NA Current Limiting
Voltage480/277 VAC
Applications
Conventional Energy, Renewable Energy and Alternative Energy Generation, Datacenters, IT Space - CI, Hyper Converged, Marine Vessels and Equipment, Convenience Receptacle Circuits, Motor Control Circuits, Load Circuits Leaving The Equipment, HACR Equipment, PLC I/O Points, Computers, Power Supplies, Control Instrumentation, Relays, UPS, Power Conditioners and Circuit Protection Applications
Warranty
1 year
Features
- Current limiting design provides fast short-circuit interruption that reduces the let-through energy, which can damage the circuit
- Thermal magnetic over current protection
- Trip-free design breaker can not be defeated by holding the handle in the On position
- A color coded red/green indicator provides immediate visual indication of device status (green for Off, red for On) and isolation function
- Power to the circuit breakers can be fed from the line or load side
- Captive screws cannot be lost
- To save installation time, bus connectors and feeder terminal facilitate mounting and wiring of multiple miniature circuit breaker arrays in control panel assemblies
- SWD (switching duty) suitable for switching fluorescent lighting loads
- C curve devices are suitable for applications where medium levels of inrush current are expected
- C curve devices provide a medium magnetic trip point
