Cutler-Hammer Series FAZ-B1/1-SP
EATON FAZ-B1/1-SP Supplementary Protector, 240/415 V AC, 1 A, 7.5 to 15 kA Interrupt, 1 Poles, Thermal Magnetic Trip
Cutler-Hammer Series FAZ-B1/1-SP
EATON FAZ-B1/1-SP Supplementary Protector, 240/415 V AC, 1 A, 7.5 to 15 kA Interrupt, 1 Poles, Thermal Magnetic TripOut of Stockmore info
|
Out of Stockmore info
|
Product Description
EATON Supplementary Protector, Series: FAZ, 240/415 V AC, 1 A, 50/60 Hz Frequency, 7.5 to 15 kA Interrupt, Thermal Magnetic Trip, 1 Pole, Line/Load Side Terminal Connection, 18 to 4 AWG Wire, IP20 Enclosure, DIN Rail Mounting, -40 to 167 deg F, 0.7 in W x 2.36 in D x 3.15 in H Dimensions, Nylon
Attributes
Documents
Applications
Features
Attributes
Actuator TypeHandle
Connection TypeLine/Load Side Terminal
Country of OriginRO
Dimensions0.7 in W x 2.36 in D x 3.15 in H
Enclosure TypeIP20
Frequency Rating50/60 Hz
Horsepower15/hp Standard Fuse/30 hp Time Delay
Interrupt Rating7.5 to 15 kA
ManufacturerEaton
MaterialNylon
Mounting TypeSurface
Number of Poles1
Number of Wires3
Phase1/3 ph
SeriesFAZ
Short Circuit Current Rating100 kA
Size of Wire18 to 4 AWG
Temperature Rating-40 to 167 deg F
Trip TypeThermal Magnetic
TypeGeneral Duty Non-Fusible
Voltage240/415 VAC
Applications
Appliances, Business Equipment, Control Circuits, Circuit Protection, Lighting, Supplementary Protection, Industrial Applications, Conventional Energy, Renewable Energy and Alternative Energy Generation, Datacenters, IT Space - CI, Hyper Converged, Marine Vessels and Equipment
Features
- Complete range of UL 1077 recognized DIN rail mounted miniature circuit breakers up to 63 A current rating
- Current limiting design provides fast short-circuit interruption that reduces the let-through energy, which can damage the circuit
- Thermal magnetic over current protection
- Six levels of short circuit protection, categorized by B, C, D, K, S and Z curves
- Trip-free design breaker can not be defeated by holding the handle in the On position
- Captive screws cannot be lost
- Field installable shunt trip and auxiliary switch subsequent mounting
- Contact position indicator (red/green)
- Possibility for sealing the toggle in "On/Off" position
