Cutler-Hammer Series HMCP100R3C
Cutler-Hammer HMCP100R3C Motor Circuit Protector, 600 VAC, 250 VDC, 100 A, 3 Poles, Magnetic Trip
Cutler-Hammer Series HMCP100R3C
Cutler-Hammer HMCP100R3C Motor Circuit Protector, 600 VAC, 250 VDC, 100 A, 3 Poles, Magnetic TripIn Stock: 2more info
|
BrandCutler-Hammer Series
MFG #HMCP100R3C
Werner Part #24810
UPC786679150856
In Stock: 2more info
|
BrandCutler-Hammer Series
MFG #HMCP100R3C
Werner Part #24810
UPC786679150856
Product Description
Cutler-Hammer Motor Circuit Protector, Series: C Series, 600 VAC, 250 VDC, 100 A, F Frame, Magnetic Trip, 300 to 1000 A Trip, 3 Pole, 3.38 in L x 4.13 in W x 6 in H Dimensions
Attributes
Documents
Features
Attributes
Connection TypeLoad
Country of OriginDominican Republic
Dimensions3.38 in L x 4.13 in W x 6 in H
Enclosure TypeNEMA AB1-1993
FrameF
Frequency Rating50/60 Hz
Interrupt Rating35/65 kA
ManufacturerEaton
Mounting TypeBolted-On
Number of Poles3
Phase3
SeriesC Series
Size of Wire4 AWG to 350 kcmil
Temperature Rating40 deg C
Trip Range300 to 1000 A
Trip TypeMagnetic
TypeType JD Standard Interrupting Capacity
Voltage600 VAC, 250 VDC
Features
- NEMA 3 starter
- 23 to 84.5 A motor full load current amperes
- A to H cam setting
- Non-aluminum termina
