Cutler-Hammer Series FAZ-C5/1-NA-L
EATON FAZ-C5/1-NA-L FAZ-NA UL 489 Branch Circuit Breaker, 240 V, 5 A, 10, 15 kAIC Interrupt, 1 Poles, Thermal Magnetic Trip
Cutler-Hammer Series FAZ-C5/1-NA-L
EATON FAZ-C5/1-NA-L FAZ-NA UL 489 Branch Circuit Breaker, 240 V, 5 A, 10, 15 kAIC Interrupt, 1 Poles, Thermal Magnetic TripOut of Stockmore info
|
Out of Stockmore info
|
Product Description
EATON FAZ-C5/1-NA-L, UL 489 Branch Circuit Breaker, Series: FAZ-NA, 240 V, 5 A, 50 to 60 Hz Frequency, 10, 15 kAIC Interrupt, Thermal Magnetic Trip, 5 - 10X Trip, 1 Pole, Toggle Actuator, Screw Connection, 18 AWG Wire, DIN Rail Mounting, 105 mm H x 17.7 mm W Dimensions
Attributes
Documents
Applications
Features
Attributes
Connection TypeScrew
Country of OriginES
Frequency Rating50 to 60 Hz
Interrupt Rating10, 15 kAIC
ManufacturerEaton
Number of Poles1
Trip TypeThermal Magnetic
Applications
Electrical Assemblies, Panels & EOEM - Electrical Assemblies and EOEMs - Other
Features
- Six levels of short-circuit protection, categorized by B, C, D, K, S and Z curves
- Trip-free design
- Easy installation on DIN rail
- Breaker cannot be defeated by holding the handle in the ON position
- Power to the circuit breakers can be fed from the line or load side
- A color-coded red and green indicator provides immediate visual indication of device status green for OFF, red for ON and isolation function
- Module width of only 17.5 mm per pole
- Thermal-magnetic overcurrent protection
- Current limiting design provides fast short-circuit interruption that reduces the let-through energy that can damage the circuit
